Accustic Arts - Amp VI Stereo Amplifier

Accustic Arts - Amp VI Stereo Amplifier

$66,990.00
          (0 reviews)
Out of stock
+
  Add to Wishlist
Accustic Arts ® AMP VI – Our statement in terms of audiophile power amplifiers!
AMP VI Stereo Amplifier Highlights

- In response to numerous customer requests for more power, we have once again increased the output power of our reference power amplifier

- Dual-mono reference power amplifier with completely isolated power supply for each amplifier channel

- 40 selected MOS-FET output transistors of highest quality

- 2 magnetically shielded and encapsulated toroidal core transformer of premium quality for highest output reserves

- Gold-plated contact surfaces ( components ) improve the contact resistance of the AMP VI

- Optimum smoothing thanks to more than 220,000 µF power supply capacity; premium quality capacitors ( “Made in Germany” )

- Very high damping factor for perfect speaker control

- ACCUSTIC ARTS® damping factor linearization ( switchable )

- Professional protective circuit against clipping, HF oscillations and too high DC offset

- Integrated switch-on current limitation for highest operational safety

- Balanced Input ( XLR ) & unbalanced input ( RCA ) – the inputs are switchable

- All used components and parts are selected & of highest quality

- Very high quality, gold-plated bi-wiring/bi-amping speaker terminal

- Extremely stable and resonance optimized, massive aluminum housing; inlay made of massive, high gloss polished and chromed brass

- ACCUSTIC ARTS® AMP VI is “Handmade in Germany”

Specifications

Voltage Gain: 30.0 dB

Power Consumption without Load: approximately 240 watts

Power Supply Capacity: approximately 220,000 µF

Input Resistance: Balanced ( XLR ): 2 x 16 kΩ, Unbalanced ( RCA ): 15 kΩ

Rated Power Output ( THD+N = 0,1% ):

> 2 x 1,600 watts on 2 Ω

> 2 x 1,500 watts on 4 Ω

> 2 x 950 watts on 8 Ω

Frequency Response: 10Hz – 50 kHz +0/-0.5 dB @ 10 watts into 4 Ω

Damping Factor: > 500 at 1 kHz 10 W on 4 Ω

Signal to Noise Ratio: -96 dBA ( ref. 6.325 V )

Crosstalk: 105 dB with 1 kHz

Minimum Loudspeaker Impedance: 2 Ω

Distortion ( THD+N ): 0.003 % on 4 Ω load at 1 kHz & 10 watts

Dimensions ( H x W x D ) 12.9" x 20.9" x 21.5"

Weight: approximately 180.4 lbs + 48.5 lbs flight case
