- In response to numerous customer requests for more power, we have once again increased the output power of our reference power amplifier
- Dual-mono reference power amplifier with completely isolated power supply for each amplifier channel
- 40 selected MOS-FET output transistors of highest quality
- 2 magnetically shielded and encapsulated toroidal core transformer of premium quality for highest output reserves
- Gold-plated contact surfaces ( components ) improve the contact resistance of the AMP VI
- Optimum smoothing thanks to more than 220,000 µF power supply capacity; premium quality capacitors ( “Made in Germany” )
- Very high damping factor for perfect speaker control
- ACCUSTIC ARTS® damping factor linearization ( switchable )
- Professional protective circuit against clipping, HF oscillations and too high DC offset
- Integrated switch-on current limitation for highest operational safety
- Balanced Input ( XLR ) & unbalanced input ( RCA ) – the inputs are switchable
- All used components and parts are selected & of highest quality
- Very high quality, gold-plated bi-wiring/bi-amping speaker terminal
- Extremely stable and resonance optimized, massive aluminum housing; inlay made of massive, high gloss polished and chromed brass
- ACCUSTIC ARTS® AMP VI is “Handmade in Germany”
Specifications
Voltage Gain: 30.0 dB
Power Consumption without Load: approximately 240 watts
Power Supply Capacity: approximately 220,000 µF
Input Resistance: Balanced ( XLR ): 2 x 16 kΩ, Unbalanced ( RCA ): 15 kΩ
Rated Power Output ( THD+N = 0,1% ):
> 2 x 1,600 watts on 2 Ω
> 2 x 1,500 watts on 4 Ω
> 2 x 950 watts on 8 Ω
Frequency Response: 10Hz – 50 kHz +0/-0.5 dB @ 10 watts into 4 Ω
Damping Factor: > 500 at 1 kHz 10 W on 4 Ω
Signal to Noise Ratio: -96 dBA ( ref. 6.325 V )
Crosstalk: 105 dB with 1 kHz
Minimum Loudspeaker Impedance: 2 Ω
Distortion ( THD+N ): 0.003 % on 4 Ω load at 1 kHz & 10 watts
Dimensions ( H x W x D ) 12.9" x 20.9" x 21.5"
Weight: approximately 180.4 lbs + 48.5 lbs flight case
