Accustic Arts - Mono VI Amplifier

Accustic Arts - Mono VI Amplifier

$104,990.00
          (0 reviews)
Out of stock
+
  Add to Wishlist
Free Shipping !


MONO VI Highlights

- In response to numerous customer requests for more power, we have once again increased the output - -- power of our reference power amplifier

- Extremely powerful mono power amplifier; reference class

- 20 selected MOS-FET output transistors of finest quality

- Magnetically shielded and encapsulated toroidal core transformers of premium quality for highest output reserves

- Gold-plated contact surfaces ( components ) improve the contact resistance of the MONO VI

- Optimum smoothing thanks to more than 110,000 µF power supply capacity; premium quality capacitors - ( “Made in Germany” )

- Very high damping factor for perfect speaker control

- ACCUSTIC ARTS® damping factor linearization (switchable)

- Integrated protective circuit against clipping, HF oscillations,

- Over-temperature & too high DC offset

- Integrated switch-on current limitation for highest operational safety

- Balanced Input ( XLR ) & unbalanced input ( RCA ) – the inputs are switchable

- All used components and parts are selected and of highest quality

- Very high quality, gold-plated bi-wiring/bi-amping speaker terminal

- Extremely stable and resonance optimized, massive aluminium housing; inlay made of massive, high - -- - gloss polished and chromed brass

- ACCUSTIC ARTS® MONO VI is “Handmade in Germany

Specifications

Voltage Gain: 30.0 dB

Power Consumption Without Load: approximately 125 watts

Power Supply Capacity: approximately 110,000 µF

Input Resistance: Balanced ( XLR ): 2 x 16 kΩ, Unbalanced ( RCA ): 15 kΩ

Rated Power Output ( @ THD+N = 1 % ):

> 1,600 watts on 2 Ω

> 1,500 watts on 4 Ω

> 950 watts on 8 Ω

Signal to Noise Ratio: -96 dBA ( ref. 6.325 V )

Distortion ( THD+N ): 0.002 % on 4 Ω load at 1 kHz & 10 watts

Dimensions ( H x W x D ) 12.9" x 20.9" x 21.5"

Weight: Approximately 74 kg | 163 lbs + 48.5 lbs flight case
