A Class D amplifier is a type of audio amplifier that uses a digital switching technology to amplify audio signals. It is also known as a switching amplifier or a digital ( erroneously ) amplifier. Un- like traditional analog amplifiers, which use continuous voltage waveforms to amplify signals, Class D amplifiers employ a more efficient method that switches the input signal on and off rapidly.
Main Features
- High Efficiency - Pulse Width Modulation
- Compact Size
- Reduced Heat Dissipation
- Improved Power Handling
- Dynamic Headroom
- Flexibility
- Personalized Faceplates
- Faceplates in Black or Silver Available
Specifications
Power Output: 225 Watt into 8 Ohm & 450 Watt into 4 Ohm
Frequency Response:1Hz - 45kHz: 6 ohms-3dB
Signal To Noise: 103dB at full power
Sensitivity:1.5 volts
AC Input Voltage:115 or 230
Weight: 53 lbs | 24 kg
Dimensions: 17.75" ( W ) x 5.25" ( H ) x 16.75" ( D )
