SPECIFICATIONS

- Frequency Range: High: (1) K-70-G 1.75 inch titanium compression driver Low: (1) K-281-EP 12 inch woofer

- Frequency Response: 71 Hz - 20 kHz (-10 dB @ 57 Hz) ± 3 dB Directivity Index: 9 dB ± 2 dB 1 kHz - 17 kHz Directivity Factor: 7.9

- Speaker Dispersion Angle: Horizontal: 60° ± 15º 2 kHz - 20 kHz Vertical: 40° ± 20º 4 kHz - 20 kH

- Overload Protection: KLIP Overload Protection Circuit-HF

- Nominal Impedance: 8 ohms, minimum 4.1 ohms @ 152 H

- Maxiumum SPL: 121 dB Continuous, 127 dB Peak

- Dimensions (W x H x D):  17 x 23 x 12.6 inches

- Construction Enclosure: 3/4 inch MDF

- Mounting: Sixteen 3/8”-16 flypoints Two 5/16”-18 threaded holes

- Crossover Frequency: 900 Hz

- Power RMS:300 watts (35V)

- Sensitivity: 100 dB

- Power Peak: 1200W

- Weight: 49 lbs.

In the Box

- AC power cord
- Grille
