LUM-420-IP-BMB | LUM-420-IP-BMW |
---|---|
Outdoor Rating: IP67
|
IP67
|
Color: Black
|
White
|
Image Sensor: 4MP (2560 x 1440 Resolution)
|
4MP (2560 x 1440 Resolution)
|
Frame Rate: Max 30FPS
|
Max 30FPS
|
Shutter Speed: 1s - 1/100000s
|
1s - 1/100000s
|
Lens: 2.8 - 12mm
|
2.8 - 12mm
|
Minimum Illumination: 0.0014 lux, AGC ON; 0 lux with IR
|
0.0014 lux, AGC ON; 0 lux with IR
|
Aperture: F1.5
|
F1.5
|
Field of View: Horizontal: 109° - 46°
Vertical: 74.5° - 27.1° |
Horizontal: 109° - 46°
Vertical: 74.5° - 27.1° |
Angle: Pan: 0° - 360°
Tilt: 0° - 90° Rotation: 0° - 360° |
Pan: 0° - 360°
Tilt: 0° - 90° Rotation: 0° - 360° |
IR Range: 50 - 70m
|
50 - 70m
|
WDR: Smart IR: Yes
|
Yes
|
Backlight Compensation: 120dB
|
120dB
|
Highlight Compensation: Yes
|
Yes
|
DNR: Yes
|
Yes
|
Recording Trigger: 3D DNR
|
3D DNR
|
AI Event: Motion, Line Crossing, Intrusion, Target Counting
|
Motion, Line Crossing, Intrusion, Target Counting
|
Motion Detection: Human, Vehicle & Non-motor Vehicle Detection
|
Human, Vehicle & Non-motor Vehicle Detection
|
Image Snapshot: Yes
|
Yes
|
Yes
|
Yes
|
Main Stream: Up to 4MP H.265+
2nd Stream: 704 x 480 H.264 3rd Stream: 704 x 480 H.264 4th Stream: 1920 x 1080 H.265, H.264, MJPEG |
Main Stream: Up to 4MP H.265+
2nd Stream: 704 x 480 H.264 3rd Stream: 704 x 480 H.264 4th Stream: 1920 x 1080 H.265, H.264, MJPEG |
Microphone: No
|
No
|
SD Card Support: Yes, up to 256GB
|
Yes, up to 256GB
|
Audio Input Connectors: 1 Channel / 1 Channel
|
1 Channel / 1 Channel
|
Alarm Contact Inputs/Outputs: 1/1
|
1/1
|
Network / Ethernet Desc: PoE, IEEE802.3af
|
PoE, IEEE802.3af
|
CVBS Output: Yes (Pigtail & Test Port)
|
Yes (Pigtail & Test Port)
|
Browser Support: Chrome, Firefox, Safari, Edge, IE Mode in Edge
|
Chrome, Firefox, Safari, Edge, IE Mode in Edge
|
Power Consumption: DC12V/PoE, < 12.5W
|
DC12V/PoE, < 12.5W
|
Protection Rating: IP67
|
IP67
|
Certifications: ETL Listed, CE, FCC, NDAA Compliant, ONVIF Conformance
|
ETL Listed, CE, FCC, NDAA Compliant, ONVIF Conformance
|
Operating Temperature: -22 °F - 140°F (-30 °C - 60°C)
|
-22 °F - 140°F (-30 °C - 60°C)
|
Dimensions (W x H x D): 278.3mm x 100.2mm x88.7mm
|
278.3mm x 100.2mm x88.7mm
|
Luma Surveillance products have a 3-Year Limited Warranty. The warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use. This warranty will not apply to products that have been abused, modified, disassembled, or improperly installed. Products to be repaired under this warranty must be returned to Snap One or a designated service center with prior notification and an assigned return authorization number (RA).
