MM Input

Frequency response: RIAA or RIAA/IEC ±0 .2 dB

Input sensitivity: 5mV in for 500mV out ( at 1 kHz )

Input impedance: 47KΩ

Input capacitance: 50-400pF selectable

Gain: 40 or 46dB with +6dB function

THD+N: <0.028%

Signal to noise ratio: 95dB

Crosstalk: better than 100dB

MC Input

Frequency response: RIAA or RIAA/IEC ±0.3dB

Input sensitivity: 500μV in for 500mV out ( at 1 kHz )

Input impedance: 25Ω to 1,2KΩ selectable

Gain: 60 or 66dB with +6dB function

THD+N: <0.28%

Signal to noise ratio: 80dB

Crosstalk: better than 90dB

Output

1 pair RCA: left and right 500mV nom 10V max

Input

1 pair RCA

Power requirement

Mains voltages: 230V/115V; AC 50/60Hz

Consumption: 20 Watts maximum.

Weight & dimensions:

Unit only, unboxed: 6.59 kg

In shipping carton & inc . accessories: 10.15 kg

W x H ( incl. feet ) x D ( incl. terminals ): 440 x 105 x 390 mm

Shipping weight & dimensions: 21" x 21" x 10" , 22.4 lbs

Standard accessories

Mains lead: 10 Amp IEC
